SF Series

MODEL

SF300

SF400

SFSOO

SF600

Table travel (X*Y} mm

320*400

400*500

500*630

630*800

Table Size (mm}

500*720

600*820

700*1000

800*1200

Max. Z axis travel (mm}

300mm

300mm

300mm

300mm

Control system

LQCUT

LQCUT

LQCUT

LQCUT

U and V axis travel

+30mm, LM guide

+30mm, LM guide

+30mm, LM guide

+30mm, LM guide

Machining taper

±6°80mm

±6°80mm

±6°80mm

±6°80mm

Maximum load capacity

600kg

800kg

1000kg

1200kg

XYZ axis resolution

0.001mm

0.001mm

0.001mm

0.001mm

Repetability

0.005mm

0.005mm

0.005mm

0.005mm

Drum runout

0.005mm

0.005mm

0.005mm

0.005mm

Wire Diameter (mm}

0.12~0.22mm

0.12~0.22mm

0.12~0.22mm

0.12~0.22mm

Wire feeding speed range

1-12m/s

1-12m/s

1-12m/s

1-12m/s

Maximum processing current

BA

BA

BA

BA

Maximum Speed (Cr12, H=60mm}

:>:200 mm2/min

:>:200 mm2/min

:>:200 mm2/min

:>:200 mm2/min

Interface Module

LAN, RS232, USB

Power Rating

3kW

Multi Cut accuracy (Cr12, H=40mm}

±0.004mm

±0.004mm

±0.004mm

±0.004mm

Surface Finish (Straight cutting, H :S 40mm}

1 cut Ra 2.5µm, 2 cut Ral.6µm, 3 cut Ra0.8-1.0µm

Dimension L*W*H (mm}

1960*1620*1915

2070*1800*1920

2390*2000*2130

2650*2310*2140

Net Weight

2100 Kg

2300 Kg

2800 Kg

3500kg
