FZT Series – CNC EDM Machine
FZT Series
STANDARD ACCESSORIES
- CNC Multicut Controller ( easy autocad integrated)
- LM Guide XYZUV
- Dielectric System with Filtration Unit
- Wire Guide
- Wire alignment tool
- Clamping tool
- 2 Axis ORO
- Automatic Lubrication system
- Toolbox
- Operation Manual
OPTIONAL ACCESSORIES
- Magnetic filter
- 4th Axis Rotary Table
- Taper Cutting Attachment
- Dielectric Double filter Tank
- Power Back-Up System (UPS)
Product Details:
MODEL |
FZT-320BJ/SF |
FZT-400BJ/SF |
FZT-S00BJ/SF |
FZT-630BJ/SF |
| Table Size(mm) | 700×500 | 820×600 | 1000×700 | 1200×800 |
| Table travel(X/Y) (mm) | 400×320 | 500×400 | 630×500 | 800×630 |
| Max. cut thickness (mm) | 300 | 300 | 400 | 400 |
| Molybdenum wire Dia.(mm) | (Molybdenum wire) c.p 0.10 – 0.22 | |||
| Cutting speed (mm2/min) | Standard:120-140, max. cutting speed: 160-180 | |||
| Wire Speed (m/Sec) | 12,9,7,5,2 | |||
| Max. cutting angle | ±3°/lO0mm | |||
| Process accuracy (mm) | (Multi-cut): 10x10x30(Square):S0.006; (one time out):S0.012 | |||
| (Multi-cut): (Octagon):S0.009; (Straightness):S0.006/50mm | ||||
| Process Roughness(Ra.um) | (Multi-cut): Ras 0.9 (Micro-pulsepower Ra :S 0.8) (Singe-cut): Ra :S 1.9 | |||
| Driving motor | Stepper motor /AC servo motor*{Optional) | |||
| Guide screw and track | Precision ball screw/Linear guide way | |||
| Tension system | three stage (0/1/2) tension adjustable | |||
| Power supply | 415V/50Hz, 2.5 Kw | |||
| Max. workpiece weight(kg) | 450 | 600 | 1000 | 1200 |
| Weight(kg) | 1500 | 1700 | 2600 | 3200 |
| Dimension(mm) | 1750x1300x2000 | 1900x1450x2000 | 2050x1850x2100 | 2250x2050x2100 |
FZT Series CNC EDM Machine – High Precision & Performance
Introduction to FZT Series CNC EDM Machines
The FZT Series CNC EDM Machine is designed to meet the most demanding industrial requirements with superior accuracy, reliability, and efficiency. At CNC EDM Machine, we provide world-class solutions including CNC EDM Wire Cut Machines, CNC EDM Die Sinking Machines, and CNC EDM Spark Erosion Machines under the FZT Series to ensure unmatched machining performance.
With advanced technology, the FZT Series CNC EDM Machine is trusted in industries such as aerospace, automotive, medical devices, electronics, and tool & die making. Whether it’s precision cutting, mold creation, or spark erosion, the FZT Series guarantees accuracy and consistency.
Why Choose FZT Series CNC EDM Wire Cut Machine?
The FZT Series CNC EDM Wire Cut Machine provides high-speed, precise cutting for complex geometries and hard materials. Its benefits include:
Micron-level accuracy for intricate designs
Automatic wire threading system for efficiency
Smooth surface finish with reduced polishing needs
Stable wire tension control for consistent quality
Energy-efficient operations reducing production costs
FZT Series CNC EDM Die Sinking Machine – Ideal for Mold Manufacturing
The CNC EDM Die Sinking Machine in the FZT Series is perfect for creating complex cavities and molds with deep precision. It offers:
Advanced spark erosion technology for accurate cavity machining
Robust structure ensuring long-term durability
Reduced tool wear for cost-effective production
User-friendly CNC controls for easy programming
CNC EDM Spark Erosion Machine – Cutting Tough Materials with Ease
The FZT Series CNC EDM Spark Erosion Machine is engineered to cut hard and exotic metals effortlessly using controlled spark erosion. Key advantages include:
Precise shaping of materials like titanium and tungsten carbide
Minimal mechanical stress on workpieces
Consistent results in batch production
Faster machining times for industrial applications
Benefits of FZT Series CNC EDM Machine
By investing in the FZT Series CNC EDM Machine, industries experience:
Superior cutting accuracy for complex designs
Reduced material wastage saving costs
Automation features for high productivity
Long-lasting performance with minimal maintenance
Versatility for wire cut, die sinking, and spark erosion machining
Applications of FZT Series CNC EDM Machines
The FZT Series is widely used in:
Tool & Die Making
Aerospace Components
Automotive Precision Parts
Medical Device Manufacturing
Electronics and Micro Components
Conclusion
The FZT Series CNC EDM Machine is the perfect blend of precision, efficiency, and reliability. With advanced models for wire cut, die sinking, and spark erosion, the FZT Series is trusted by industries worldwide for delivering consistent, high-quality results.
The FZT Series CNC EDM Machine is used for high-precision machining, including wire cutting, die sinking, and spark erosion applications across various industries.
A CNC EDM Wire Cut Machine uses a fine wire electrode to cut intricate shapes, while a CNC EDM Die Sinking Machine uses a shaped electrode to form cavities and molds. Both are part of the FZT Series.
Yes, it can cut hard metals such as tungsten carbide, titanium, and hardened steel with precision.
Industries such as aerospace, automotive, medical devices, tool & die making, and electronics extensively use the FZT Series CNC EDM Machines.
You can explore details and request a quote directly at FZT Series CNC EDM Machine.
